3160-A2-GB24-10

March 2001

B-1

B

Technical Specifications

Overview

The technical specifications for the standalone DSU/CSUs are listed in

Table B-1,

Models 3160/3164/3165 DSU/CSU’s Technical Specifications

. The technical

specifications for the carrier-mounted DSU/CSUs are listed in the

ACCULINK

3151 CSU and 3161 DSU/CSU General Information Guide

.

Table B-1.

Models 3160/3164/3165 DSU/CSU’s Technical Specifications (1 of 2)

Specifications

Criteria

POWER REQUIREMENTS
Standard:

AC Power Module

Optional dc (3164 only):

+24 Vdc

–48 Vdc

–48 Vdc Redundant

Refer to the labeling on the ac power module for input
requirements

+20 Vdc to +32 Vdc, 0.50A

–38 Vdc to –60 Vdc, 0.25A

–38 Vdc to –60 Vdc, 0.25A

POWER CONSUMPTION
AND DISSIPATION

3160

3164

3165

8.4 watts, 28.7 Btu per hour at 115 Vac, 60 Hz
(includes external transformer)

12.0 watts, 41 Btu per hour at +24 and –48 Vdc
16.0 watts, 55.0 Btu per hour at 115 Vac, 60 Hz (includes
external transformer)

7.5 watts, 25.6 Btu per hour at 115 Vac, 60 Hz
(includes external transformer)
6.6 watts, 22.5 Btu per hour at 100 Vac, 50 Hz
(includes external transformer)

ENVIRONMENT

Operating Temperature
Storage Temperature
Relative Humidity Shock and
Vibration

32

°

F to 122

°

F (0

°

C to 50

°

C)

–4

°

F to 158

°

F (–20

°

C to 70

°

C)

5%—95% (noncondensing)
Withstands normal shipping and handling
