F. SNMP MIB Objects
3160-A2-GB24-10 March 2001 F-31
Test–>Ptrns–>Mon–>QRSS–>NET
Test–>Ptrns–>Abort–>Mon–>NET
Set ifExtnsTestType for Net T1 to testMonQRSS
Set ifExtnsTestType for Net T1 to noTest
Test–>Ptrns–>Mon–>QRSS–>Prt n
Test–>Ptrns–>Abort–>Mon–>Prt n
Set ifExtnsTestType for port n to testMonQRSS
Set ifExtnsTestType for port n to noTest
Test–>Ptrns–>Mon–>511–>Prt n
Test–>Ptrns–>Abort–>Mon–>Prt n
Set ifExtnsTestType for port n to testMon511
Set ifExtnsTestType for port n to noTest
Cnfig–>Load Config–>Save Set devConfigAreaCopy to the desired choice(Active to
Customer1, etc.)
Cnfig–>Activ–>Edit–>DTE–>DTE–>Framing Set/Display dsx1LineType for DTE T1 to dsx1ESF or dsx1D4
Cnfig–>Activ–>Edit–>DTE–>DTE–>Coding Set/Display dsx1LineCoding for DTE T1 to dsx1B8ZS or
dsx1AMI
Cnfig–>Activ–>Edit–>Port–>Prtn–>Port Type Display rs232PortType for port n to rs422 or v35
Cnfig–>Activ–>Edit–>Port–>Prt n–>TxClock Set/Display rs232SyncPortClockSource for port n to internal or
external
Cnfig–>Activ–>Edit–>NET–>NET Framing Set/Display dsx1LineType for NET T1 to dsx1ESF or dsx1D4
Cnfig–>Activ–>Edit–>NET–>NET Coding Set/Display dsx1LineCoding for NET T1 to dsx1B8ZS or
dsx1AMI
Cnfig–>Activ–>Edit–>NET–>ANSI PRM
Cnfig–>Activ–>Edit–>NET–>Mgmt Link
Set/Display dsx1Fdl for NET T1 to dsx1Ansi-T1-403 or
dsx1Att-54016 or dsx1other
Cnfig–>Activ–>Edit–>Chan–>DTE–>Assign Set/Display dsx1FracNumber and dsx1FracIfindex for DTE T1
Cnfig–>Activ–>Edit–>Chan–>DTE–>Voice Display dsx1SignalMode for DTE T1 to none or robbedBit
Cnfig–>Activ–>Edit>Chan–>Prt n–>Assign To
Cnfig–>Activ–>Edit–>Chan–>Display
Set/Display dsx1FracNumber and dsx1Fracifindex for DTE or
Net T1
Cnfig–>Activ–>Edit–>Chan–>Prt n–>Port Rate Display rs232PortInSpeed or rs232PortOutSpeed for port n
Cnfig–>Activ–>Edit–>Gen–>Clock Src Display dsx1TransmitClockSource for DTE T1 or NET T1
Cnfig–>Activ–>Edit–>User–>Com Rate
Cnfig–>Activ–>Edit–>User–>Aux Rate
Cnfig–>Activ–>Edit–>User–>Modem Rate
Set/Display rs232PortInSpeed or rs232PortOutSpeed for COM,
AUX, or MODEM port
Cnfig–>Activ–>Edit–>User–>Char Length
Cnfig–>Activ–>Edit–>User–>MChar Len
Set/Display rs232AyncPortBits for COM or MODEM port
Cnfig–>Activ–>Edit–>User–>CParity
Cnfig–>Activ–>Edit–>User–>MParity
Set/Display rs232AyncPortParity for COM or MODEM port
Cnfig–>Activ–>Edit–>User–>CStop Bits
Cnfig–>Activ–>Edit–>User–>MStop Bits
Set/Display rs232AyncPortStopBits for COM or MODEM port
Table F-1. SNMP MIB to Front Panel Command Cross-Reference (3 of 3)
Front Panel Command SNMP MIB Object
