10baset connector – Paradyne 3161 User Manual
Page 226
E. Pin Assignments
E-4
March 2001
3160-A2-GB24-10
10BaseT Connector
Use a standard 10BaseT cable to connect the DSU to an Ethernet LAN. A cable is
provided with the DSU.
The following table defines the pinouts for the 10BaseT port. It is an 8-pin,
unkeyed jack.
Use
Pin #
Transmitted Data +
1
Transmitted Data –
2
Received Data +
3
NC
4
NC
5
Received Data –
6
NC
7
NC
8
NC = Not connected (unused).
