F. SNMP MIB Objects

F-30

March 2001

3160-A2-GB24-10

Stat–>LED–>Prtn:

DTR
CTS
RTS

Read:

rs232InSigState from rs232InSigName == dtr
rs232outSigState
from rs232OutSigName == ctr
rs232InSigState
from rs232InSigName == rts

Stat–>ID:

Ser
Mod
SRev
HRevCCA1
HRevCCA2

Read the sysDescr object from the System Group

Test–>Rlpbk–>LLBUP

Set dsx1SendCode to

dsx1SendLineCode

Test–>Rlpbk–>LLBDN

Set dsx1SendCode to

dsx1SendResetCode

Test–>Rlpbk–>54UP–>Prt

n

Set IfExtnsTestType for port

n to testSendV54Up

Test–>Rlpbk–>54DN–>Prt

n

Set IfExtnsTestType for port

n to testSendV54Down

Test–>Rlpbk–>FT1UP–>Prt

n

Set IfExtnsTestType for port

n to testSendFT1UP

Test–>Rlpbk–>FT1DN–>Prt

n

Set IfExtnsTestType for port

n to testSendFT1Down

Test–>Lpbk–>LLB

Test–>Lpbk–>bort–>LLB

Set dsx1LoopbackConfig for Net T1 to

dsx1LineLoop

Set dsx1LoopbackConfig for Net T1 to

dsx1NoLoop

Test–>Lpbk–>PLB

Test–>Lpbk–>Abort–>PLB

Set dsx1LoopbackConfig for Net T1 to

dsx1PayloadLoop

Set dsx1LoopbackConfig for Net T1 to

dsx1NoLoop

Test–>Lpbk–>DLB

Test–>Lpbk–>Abort–>DLB

Set dsx1LoopbackConfig for DTE T1 to

dsx1LineLoop

Set dsx1LoopbackConfig for DTE T1 to

dsx1NoLoop

Test–>Lpbk–>RLB

Test–>Lpbk–>Abort–>RLB

Set dsx1LoopbackConfig for DTE T1 to

dsx1PayloadLoop

Set dsx1LoopbackConfig for DTE T1 to

dsx1NoLoop

Test–>Lpbk–>DCLB–>Prt

n

Test–>Lpbk–>Abort–>DCLB–>Prt

n

Set IfExtnsTestType for port

n to testFullDuplexLoopBack

Set dsx1LoopbackConfig for port

n to noTest

Test–>Lpbk–>DTLB–>Prt

n

Test–>Lpbk–>Abort–>DTLB–>Prt

n

Set IfExtnsTestType for port

n to testLoopDTLB

Set dsx1LoopbackConfig for port

n to noTest

Test–>Ptrns–>Send–>ORSS–>NET

Test–>Ptrns–>Abort–>Send–>NET

Set dsx1SendCode for Net T1 to

dsx1SendQRSS

Set dsx1SendCode for Net T1 to

dsx1SendNoCode

Test–>Ptrns–>Send–>QRSS–>Prt

n

Test–>Ptrns–>Abort–>Send–>Prt

n

Set IfExtnsTestType for port

n to testSendQRS

Set IfExtnsTestType for port

n to noTest

Test–>Ptrns–>Send–>1in8

Test–>Ptrns–>Abort–>Send–>NET

Set dsx1SendCode for Net T1 to

dsx1SendOtherTestPattern

Set dsx1SendCode for Net T1 to

dsx1SendNoCode

Test–>Ptrns–>Send–>511–>Prt

n

Test–>Ptrns–>Abort–>Send–>Prt

n

Set IfExtnsTestType for port

n to testSend511

Set IfExtnsTestType for port

n to noTest

Table F-1.

SNMP MIB to Front Panel Command Cross-Reference (2 of 3)

Front Panel Command

SNMP MIB Object
