3. Using the Front Panel

3-6

March 2001

3160-A2-GB24-10

Table 3-1.

System LEDs

Name

Color

Meaning

OK

Green

Indicates the current operational state of the DSU/CSU.

ON: The DSU/CSU is operational and has power.

OFF: The DSU/CSU is performing a power-on self-test or a
system failure has occurred.

BLINKING: A software download is in progress.

FAST BLINK: The carrier-mounted DSU/CSU is currently
selected by the SDCP.

FAIL

Yellow

Indicates a system failure or a self-test.

ON: A device error/fault is detected or a reset has just occurred.

OFF: No system failures are detected.

BLINKING: A self-test is in progress.

TEST

Yellow

A system test is in progress.

ON: A loopback or pattern test has been initiated either locally, by
the network, or externally.

OFF: No tests are active.
