3160-A2-GB24-10 March 2001 3-1
3
Using the Front Panel
Overview
This chapter shows how to use:
T The standalone DSU/CSU front panel and 3000 Series Carrier control panel
to:
— Display unit identity
— Reset the DSU/CSU
T The front panel LEDs to:
— Monitor the status of the DSU/CSU
— Monitor the status of the network
— Monitor the status of the DTE
NOTE:
Additional information for the carrier-mounted DSU/CSU is located in the
ACCULINK 3151 CSU and 3161 DSU/CSU General Information Guide and
the COMSPHERE 3000 Series Carrier Installation Manual .
Front Panel
The standalone DSU/CSU front panel ( Figure 3-1, Standalone DSU/CSU Front
Panel ) consists of an LCD, a keypad, test jacks, and 12 LEDs. The
carrier-mounted DSU/CSU faceplate contains test jacks and 12 LEDs; however,
the LCD and keypad are located on the Shared Diagnostic Control Panel (SDCP)
of the 3000 Series Carrier. For more information about the SDCP, refer to the
COMSPHERE 3000 Series Carrier Installation Manual .
NOTE:
You can display a graphical representation of the DSU/CSU front panel on an
attached PC (see
Appendix H, Front Panel Emulation ).
