3. Using the Front Panel
3-14 March 2001 3160-A2-GB24-10
If you chose T1, the LED Display screen lists the LED signals, two at a time,
on the second line. A vertical bar at the left of the LED name indicates the
condition is ON, while an underscore indicates the condition is Off.
If you chose a port, the Port n LEDs screen lists the LED signals, two at a time,
on the second line. A vertical bar at the left of the LED name indicates the
condition is ON, while an underscore indicates the condition is Off.
5. Use the and keys to scroll LED names onto the screen.
F1 F2 F3
LED Display:
_Test _NetSig
F1 F2 F3
Port n LEDs:
_DTR _TXD
