RIO Remote I/O System User Guide
RIO system components
Page 23
Chapter 1 Introduction
Remote Terminal Adaptors
Remote Terminal Adaptors (RTAs) are basically serial connection blocks which provide a
number of ports depending on type. RTAs come in three main varieties, the RTA 8 (providing
8 ports) and RTA 16 and RRC16 (providing 16 ports). Each unit is available in a number of
variations as shown in the next table.
See also Installing Remote Terminal Adaptors (RTAs) on page 161 in Chapter 2
Installing hardware and software .
Long Distance Module (LDM)
The RIO Long Distance Module (LDM) allows you to extend your RIO system via a leased
line. Using a RIO Long Distance Module you can make connections over thousands of miles
using synchronous (X.21/X.21bis) or asynchronous interfaces. The long distance module
comprises two long distance units (LDUs). One is installed at the host site and the other at
the remote site. See also
Installing a Long Distance Module (LDM) on page 177 in
Chapter 2 Installing hardware and software .
RTA type
Number
of ports
Type For details of installation see...
Currently available products
RRC16/RJX 16 High speed RS232 asynchronous
RJ45 serial ports with ESD
protection RRC16 Remote
Concentrator
on page 168
RTA8RJX 8 RS232 RJ45 with ESD protection RTA8 8 port Remote Terminal
Adaptors
on page 162 RTA8/RJ 8 RS232 RJ45
RTA8/DX 8 RS232 DB25 Female/ESD
Protected
RTA8/D 8 RS232 DB25 Female
RTA8/MX* 8 RS232 DB25 Male/ESD Protected
RTA8/M 8 RS232 DB25 Male
RTA8/PX* 8 Comprising 1 Centronics Parallel
DB25, 7 RS232 DB25 Female/ESD
Protected
RTA8/P 8 Comprising 1 Centronics Parallel
DB25, 7 RS232 DB25 Female
RTA8/422 8 RS422 DB25 Female
Older products
RTA16/DX 16 RS232 DB25 with ESD protection RTA16 16 port Remote
Terminal Adaptors
on page 165 RTA16/D 16 RS232 DB25 Female
