RIO Remote I/O System User Guide
Cable connector pinouts
Page 218
Chapter 3 RIO Cabling information
DB25 parallel male to centronics parallel
Note
The following pinout is included for information only and shows the DB25 pinout only. If you
require this type of cable, we recommend obtaining a suitable standard PC parallel printer cable
rather than making one.
* Denotes active low.
Pin
Signal
Direction
Description
1
STROBEN*
Output
PSTROBE
2
D0
Output
DATA 1
3
D1
Output
DATA 2
4
D2
Output
DATA 3
5
D3
Output
DATA 4
6
D4
Output
DATA 5
7
D5
Output
DATA 6
8
D6
Output
DATA 7
9
D7
Output
DATA 8
10
PACKN*
Input
ACK
11
PBUSY
Input
BUSY
12
PPE
Input
PE
13
PSLCT
Input
SLCT
14
AUTOFDXT*
Output
AUTOFEED
15
PERRORN*
Input
FAULT
16
PINITN*
Output
INPUT PRIME
17
PSLINN*
Output
SLCT IN
18
GND
—
GROUND
19
GND
—
GROUND
20
GND
—
GROUND
21
GND
—
GROUND
22
GND
—
GROUND
23
GND
—
GROUND
24
GND
—
GROUND
25
GND
—
GROUND
