RIO Remote I/O System User Guide
Page 199
Chapter 3 RIO Cabling information
RIO Remote I/O System
User Guide
Chapter 3 RIO Cabling information
You need to read
this chapter if you
want to... You need to read this chapter if you want cabling information for the Perle RIO serial
connectivity system hardware.
This chapter provides cabling and connector pinout information for the Perle RIO system.
Included are details of about which cables to use, their pinouts and details of standard cables
for use with RIO products available from Perle.
This chapter includes the following sections;
• Mini DIN pinouts on RIO host cards on page 200
• RTA connector pinouts on page 201
• Connecting RIO host cards to RTAs on page 207
• Connecting RTAs to terminals on page 207
• Connecting RTAs to modems on page 208
• Connecting RTAs to parallel printers on page 209
• Connecting RTAs to serial printers on page 210
• Cable connector pinouts on page 211
• RIO cables available from Perle on page 219
• Fibre optic link (FOLK) cable specifications on page 221
• Loopback connector pinouts on page 222
