User’s Manual of WGSD-1022/WGSD-8000
- 30 –
4.1 Main Screen
The Switch provides a Web-based browser interface for configuring and managing the Switch. This interface allows you to
access the switch using the Web browser of your choice. This chapter describes how to use the switch’s Web browser interface
to con-figure and manage the switch.
Figure 4-1
Via the Web-Management, the administrator can setup the WGSD-Switch by select the functions those listed in the Main
Function. The screen in Figure 4-2 appears.
Figure 4-2 WGSD-Switch Main Funcrions Menu
The following functions can be configured here:
„ Setup
„ Port Config
„ VLAN Config
„ Statistics
„ ACL
Main Functions Menu Sub Menu
Port Link Status
Main Screen
Save Config
Description
