User’s Manual of WGSD-1022/WGSD-8000
- 146 –
• Backup This is used to backup the configuration to the local hard drive.
• Source File Type in the name and path of the file or Browse to locate the upgrade
file.
Use the Proceed button to save configuration via TFTP or HHTP that be selected.
4.12.8 Firmware Upgrade
The Firmware Upgrade screen contains the following fields:
See figure 4-76
Figure 4-76 Firmware Upgrade via TFTP
The page contains the following fields:
„ Via TFTP
• Via TFTP Defines the upgrade through a TFTP Server.
• File Type Select file type to be upgraded through a TFTP Server. The possible
field values are :
• Software Image
• Boot Code
• TFTP Server The TFTP Server IP Address that contains the source file to upgrade
from.
• Source File Specifies the name of the upgrade file on the TFTP Server.
• Destination File Type in the name and path of the file or Browse to locate the upgrade
file.
