Kodak RFS 3570 User Manual
Page 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-6 Installation (Hardware & Software) — Macintosh Computer G
2. Attach the 25-pin SCSI connector of the cable to the SCSI port on the
back of the Macintosh computer. Make sure the cable connector is
well seated by pressing it into place firmly, and then tighten both
knobs on the 25-pin SCSI cable connector.
25-pin SCSI Connector
Knobs
BACK OF MACINTOSH COMPUTER
