 Loading the Film and Slide Holders — PC G 8-3
4. Tuck the lower edge of the film under the tabs that run along the
hinge.
5. Center the film so that each frame aligns with a frame in the film
holder.
6. Snap the film holder shut.
The holder is now ready to be placed into the Scanner.
Loading 35 mm Slides into the Slide Holder
The slide holder can accommodate up to four 35 mm slides at a time.
Standard slides up to .12 in. (3 mm) thick will fit into the slide holder.
Refer to the diagram below to load slides.
ABC
R R
Slide
Orientation Label
1. Orient the slide holder as shown above with the orientation labels
facing you.
2. Place your slide into the slide holder so that images are facing you as
you would see them in real life (not mirror-imaged).
3. (Optional) Place additional slides into the holder as desired.
The holder is now ready to be placed into the Scanner.
