4.8 AT+CMUX
s
m
obile
MC55_ATC_V01.05
Page 100 of 469
2/10/04
Confidential / Released
Refer to
which provides a detailed description of the multiplex architecture and step-by-step instructions of
how to install and configure the multiplex mode. The WinMUX2k driver and its source files can be supplied on
request. Please contact your local distributor to obtain the latest installation software and user's guide.
Parameter Description
Multiplexer transparency mechanism
0
Basic option
Subparameters defined in GSM07.07 are adjusted for control and logical channels as follows
0
UIH frames used only (control channel)
Notes
• The write command is used to enter the multiplex mode. The setup of the logical channels is initiated by the
TE, i.e. the TE acts as initiator. This means that the TE shall ensure that logical channels are established
before any further actions on the channels can be started.
• There is a timeout of five seconds, if the multiplexer protocol is enabled and no multiplexer control channel is
established. The GSM engine returns to AT command mode.
• The parameter maximum frame size (N1) of
in GSM07.10 is fixed to 97 and cannot be changed.
All other parameters are not available.
4.8.1
Restrictions on Multiplex mode
When the serial interface ASC0 is in multiplex mode, data and fax calls can only be set up on logical channel 1.
Due to this restriction, AT commands have a different behavior on channels 2+3 compared to channel 1. Several
commands are not available, others return different responses. This chapter summarizes the concerned com-
mands. For general rules and restrictions to be considered in Multiplex mode please refer to
.
Table 4.1:
Availability of AT Commands on Virtual Channels
(num)
(num)
Command
Behavior on channel 1
Behavior on channel 2+3
not usable, but see note
2)
not usable, but see note
2)
as described
not usable
as described
not usable
AT+CG... (GPRS commands)
as described
see note
3)
AT+F... (Fax commands)
as described
not usable
as described
not usable
as described
no Data Calls
as described
no Data Calls
as described
not usable
as described
not usable
as described
not usable
