Table 2. Magstar 3494 Cartridge Capacity (continued)
Model or Frame
Without
Dual Gripper
With
Dual Gripper
Model D10
(without 3490 Model CxA/F1A)
400 360
Model D10, FC 5300
(with 3490 Model CxA/F1A)
300 270
Model D12, FC 5500 400 360
Model D12, FC 5302
(with one or two 3590 Models B1A)
335 305
Model D12, FC 5302, FC 5502
(with three or four 3590 Models B1A)
290 260
Model D12, FC 5302 (with RPQs), FC
5502 (with RPQ)
(with five or six 3590 Models B1A)
250 230
Model D14
(without 3590 Model B1A)
400 360
Model D14, FC 5304
(with one or two 3590 Models B1A)
345 305
Model D14, FC 5304 (with RPQ)
(with three or four 3590 Models B1A)
305 275
Model B16, or FC 5500 400 360
Model B18 0 0
Model HA1 (service bays) 0 0
Notes:
1. The optional Convenience Input⁄Output Station feature reduces the cartridge capacity by
30 cartridges (FC 5210) or 80 cartridges (FC 5230).
2. With dual grippers installed, the optional Convenience Input⁄Output Station feature
reduces the cartridge capacity by 26 cartridges (FC 5210) or 72 cartridges (FC 5230).
3. Selecting the high-capacity input/output station facility reduces the cartridge capacity,
depending on the options chosen (see “High-Capacity Input/Output Facility” on page 16).
4. One cell is reserved for ejecting cartridges if the optional Convenience Input⁄Output
Station feature is not installed and the high-capacity output facility is not defined.
5. A maximum of two cells are reserved for certain service representative functions. When
the high availability unit is installed, there are no cells reserved in the L1x unit for
service functions.
6. One cell is reserved for error-recovery operations for configurations without the high
availability unit and two cells are reserved for error-recovery operations for
configurations with the high availability unit.
