Using the Operator Menu
The Operator menu (see Figure 42) is displayed after the following:
v The library manager is powered on.
v The Copyright panel is displayed.
v The Auto mode/Online state process has completed.
The Operator menu panel consists of a title bar, an action bar, and initially, the
System Summary window. See Figure 43.
You can select any of the action items from the Operator menu. When one of the
action items is selected, a pull-down menu is displayed with additional information
or selections.
Selection
Pull-Down Menu Selections
Mode Allows selection of an operational mode and state (see “Using the Mode
Pull-Down” on page 99).
Status
Displays subsystem status and statistics (see “Using the Status Pull-Down”
on page 109).
Queues
Displays the contents of the command queues (see “Using the Queues
Pull-Down” on page 137).
Database
Provides database search procedures for volumes (see “Using the
Database Pull-Down” on page 139).
Commands
Provides operator commands and allows responses to intervention-required
conditions (see “Using the Commands Pull-Down” on page 152).
Figure 42. Operator Menu
Figure 43. System Summary Pop-Up Window
