Category
Category change has been made to.
Parameters
Additional information, not currently supported.
Example:
3494 C2444 UNSOL 16 180 FF01 20 *Device Category Change
CHCK1 Library Manager SNMP Traps
This section discusses the format of the Library Managers CHCK1 messages. All
CHCK1 Library Manager SNMP Traps have the same format.
The format for CHCK1 Library Manager SNMP Traps is as follows:
3494 [Library Sequence Number] CHCK1 [Errorcode] [Modifier] *A CHECK1 with
errorcode: [Errorcode], and modifier: [Modifier], has occurred on [Library
Sequence Number]
Example:
3494 C2444 CHCK1 BDDD 230 *A CHECK1 with errorcode: BDDD, and modifier:
230, has occurred on C2444
Note: All Library Manager SNMP trap messages are actually one line of text; some
have been split in order to fit on the pages of this document.
In this example, a BDDD CHECK1, with modifier 230, occurred on C2444 3494
Tape Dataserver.
Errorcode
The errorcode will be a hexadecimal value between 0 and 0xFFFF
Modifier
The modifier is used by the CHECK1 for additional information about the
condition. Valid values are 0 to 64K.
TESTM Library Manager SNMP Traps
This section discusses the TESTM Library Manager SNMP trap messages. All
Library Manager TESTM SNMP trap messages have the same format.
The format is as follows:
3494 [Library Sequence Number] TESTM *{User Message}
Example:
3494 C2444 TESTM *THIS IS A TEST, 5/26/98 - 10:30 am
In this example, the user entered the string “THIS IS A TEST, 5/26/98 - 10:30 am”.
The asterix character (*) is automatically inserted in the Library Manager TESTM
message. It is intended to aid the monitor station programmer.
Using the Options Pull-Down
Figure 139 on page 227 shows the Options pull-down.
226 Magstar 3494 Tape Library Operator Guide
