Operating in Manual Mode
Figure 143 shows the Manual Mode Terminal pop-up window with the Action List
screen.
Legend:
Action
The operator task. See the following procedures for details.
VOLSER
The cartridge volume serial number.
From The place where you should find the cartridge specified in VOLSER.
To The place where you should put the cartridge.
Device
The 3490E/3590 tape drive.
Rack The physical storage address that can contain one cartridge.
? The cartridge may not be in the location specified. See Note 2.b on
page 232.
The Action List screen presents tasks to perform. Perform the actions in the
sequence listed (see Figure 143). Read the following Mount, Demount, Insert, and
Eject procedures for how to perform each action.
The following are the function keys of the Action List screen:
F1 Displays instructions for performing Manual mode tasks.
F3 Hides this pop-up window (Manual Mode Terminal). The Manual Mode
Terminal pop-up window is hidden but can be retrieved by selecting the
Mode pull-down and then selecting Manual mode.
Action List
Select an action. Press Enter to confirm action completion (except Mounts).
Action VOLSER From To
Mount WCC007 Rack 12 B 11 Device 3F1
Mount WSB392 Rack 7 C 5 Device 3F0
Mount TFW001 Device 201 Device 3F1
Mount SCR023 Rack 12 E 6 Device 3F0
Mount WRO112 Rack 3 J 13 Device 201
Mount TGB041 Rack 4 F 3? Device 200
Mount ECR223 Rack 10 D 13 Device 3F1
Mount SFC607 Rack 9 F 2 Device 3E1
Mount FGG641 Rack 11 C 10 Device 200
Eject ERV399 Rack 13 F 11
More actions are waiting.
Press the Refresh key (F9) to update the list.
F1=Help F3=HideScreen F4=Error F5=Insert F6=Review F9=Refresh F10=Locate
Figure 143. Manual Mode Terminal Pop-Up Window with Action List
