Debug Module
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor
28-43
Table 28-25. PST/DDATA Specification for User-Mode Instructions
Instruction
Operand Syntax
PST/DDATA
add.l
PST = 0x1, {PST = 0xB, DD = source operand}
add.l
Dy,
PST = 0x1, {PST = 0xB, DD = source}, {PST = 0xB, DD = destination}
adda.l
PST = 0x1, {PST = 0xB, DD = source operand}
addi.l
#,Dx
PST = 0x1
addq.l
#,
PST = 0x1, {PST = 0xB, DD = source}, {PST = 0xB, DD = destination}
addx.l
Dy,Dx
PST = 0x1
and.l
PST = 0x1, {PST = 0xB, DD = source operand}
and.l
Dy,
PST = 0x1, {PST = 0xB, DD = source}, {PST = 0xB, DD = destination}
andi.l
#,Dx
PST = 0x1
asl.l
{Dy,#},Dx
PST = 0x1
asr.l
{Dy,#},Dx
PST = 0x1
bcc.{b,w}
if taken, then PST = 0x5, else PST = 0x1
bchg.{b,l}
#,
PST = 0x1, {PST = 0x8, DD = source}, {PST = 0x8, DD = destination}
bchg.{b,l}
Dy,
PST = 0x1, {PST = 0x8, DD = source}, {PST = 0x8, DD = destination}
bclr.{b,l}
#,
PST = 0x1, {PST = 0x8, DD = source}, {PST = 0x8, DD = destination}
bclr.{b,l}
Dy,
PST = 0x1, {PST = 0x8, DD = source}, {PST = 0x8, DD = destination}
bitrev.l
Dx
PST = 0x1
bra.{b,w}
PST = 0x5
bset.{b,l}
#,
PST = 0x1, {PST = 0x8, DD = source}, {PST = 0x8, DD = destination}
bset.{b,l}
Dy,
PST = 0x1, {PST = 0x8, DD = source}, {PST = 0x8, DD = destination}
bsr.{b,w}
PST = 0x5, {PST = 0xB, DD = destination operand}
btst.{b,l}
#,
PST = 0x1, {PST = 0x8, DD = source operand}
btst.{b,l}
Dy,
PST = 0x1, {PST = 0x8, DD = source operand}
byterev.l
Dx
PST = 0x1
clr.b
PST = 0x1, {PST = 0x8, DD = destination operand}
clr.l
PST = 0x1, {PST = 0xB, DD = destination operand}
clr.w
PST = 0x1, {PST = 0x9, DD = destination operand}
cmp.l
PST = 0x1, {PST = 0xB, DD = source operand}
cmpa.l
PST = 0x1, {PST = 0xB, DD = source operand}
cmpi.l
#,Dx
PST = 0x1
divs.l
PST = 0x1, {PST = 0xB, DD = source operand}
divs.w
PST = 0x1, {PST = 0x9, DD = source operand}
divu.l
PST = 0x1, {PST = 0xB, DD = source operand}
