Power Management
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
8-16 Freescale Semiconductor
I 2 C Module Enabled Yes 2 Enabled Yes 2 Stopped No
QSPI Enabled Yes 2 Enabled Yes 2 Stopped No
DMA Timers Enabled Yes
2
Enabled Yes
2
Stopped No
Interrupt Controller Enabled Yes
2
Enabled Yes
2
Enabled Yes
2
I/O Ports Enabled No Enabled No Enabled No
Reset Controller Enabled Yes
3
Enabled Yes
3
Enabled Yes
3
Chip Configuration Module Enabled No Enabled No Stopped No
Power Management Enabled No Enabled No Stopped No
Clock Module Enabled Yes
2
Enabled Yes
2
Enabled Yes
2
Edge port Enabled Yes
2
Enabled Yes
2
Stopped Yes
2
Programmable Interrupt Timers Enabled Yes
2
Program Yes
2
Stopped No
ADC Enabled Yes
2
Program Yes
2
Stopped No
General Purpose Timer Enabled Yes
2
Enabled Yes
2
Stopped No
PWM Program No Program No Stopped No
BDM Enabled Yes 4 Enabled Yes 4 Enabled Yes 4
JTAG Enabled No Enabled No Enabled No
1
Program Indicates that the peripheral function during the low-power mode is dependent on programmable bits in the
peripheral register map.
2 These modules can generate a interrupt that exits a low-power mode. The CPU begins to service the interrupt exception
after wakeup.
3
These modules can generate a reset that exits any low-power mode.
4
The BDM logic is clocked by a separate TCLK clock. Entering halt mode via the BDM port exits any low-power mode.
Upon exit from halt mode, the previous low-power mode is re-entered and changes made in halt mode remains in effect.
Table 8-10. CPU and Peripherals in Low-Power Modes (continued)
Module
Peripheral Status
1
/ Wakeup Capability
Wait Mode Doze Mode Stop Mode
