Register Memory Map Quick Reference
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
A-14 Freescale Semiconductor
IPSBAR + 0x10_0058 Port TD Clear Output Data Register CLRTD 8
IPSBAR + 0x10_0059 Port UA Clear Output Data Register CLRUA 8
IPSBAR + 0x10_005A Port UB Clear Output Data Register CLRUB 8
IPSBAR + 0x10_005B Port UC Clear Output Data Register CLRUC 8
IPSBAR + 0x10_005C Port DD Clear Output Data Register CLRDD 8
IPSBAR + 0x10_005D Reserved — 8
IPSBAR + 0x10_005E Reserved — 8
IPSBAR + 0x10_005F Reserved — 8
IPSBAR + 0x10_0060 Reserved — 8
IPSBAR + 0x10_0061 Reserved — 8
IPSBAR + 0x10_0062 Reserved — 8
IPSBAR + 0x10_0063 Reserved — 8
IPSBAR + 0x10_0064 Reserved — 8
IPSBAR + 0x10_0065 Reserved — 8
IPSBAR + 0x10_0066 Reserved — 8
IPSBAR + 0x10_0067 Reserved — 8
IPSBAR + 0x10_0068 Port NQ Pin Assignment Register PNQPAR 16
IPSBAR + 0x10_006A Port AN Pin Assignment Register PANPAR 8
IPSBAR + 0x10_006B Port AS Pin Assignment Register PASPAR 8
IPSBAR + 0x10_006C Port QS Pin Assignment Register PQSPAR 16
IPSBAR + 0x10_006E Port TA Pin Assignment Register PTAPAR 8
IPSBAR + 0x10_006F Port TC Pin Assignment Register PTCPAR 8
IPSBAR + 0x10_0070 Port TD Pin Assignment Register PTDPAR 8
IPSBAR + 0x10_0071 Port UA Pin Assignment Register PUAPAR 8
IPSBAR + 0x10_0072 Port UB Pin Assignment Register PUBPAR 8
IPSBAR + 0x10_0073 Port UC Pin Assignment Register PUCPAR 8
IPSBAR + 0x10_0074 Port DD Pin Assignment Register PDDPAR 8
IPSBAR + 0x10_0075 Reserved — 8
IPSBAR + 0x10_0076 Reserved — 8
IPSBAR + 0x10_0077 Reserved — 8
IPSBAR + 0x10_0078 Pin Slew Rate Register PSRR 32
IPSBAR + 0x10_007C Pin Drive Strength Register PDSR 32
Table A-3. Register Memory Map (continued)
Address Name Mnemonic Size (bits)
