Interrupt Controller Module
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor 14-9
request, 0 = negate request) in the appropriate INTFRCn register. The assertion of an interrupt request via
the INTFRCn register is not affected by the interrupt mask register. The INTFRCn register is cleared by
reset.
IPSBAR
Offset: 0x0C10 (INTFRCHn)
Access: Read/write
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
R
INTFRCH[63:48]
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
INTFRCH[47:32]
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 14-5. Interrupt Force Register High (INTFRCHn)
Table 14-7. INTFRCHn Field Descriptions
Field Description
31–0
INTFRCH
Interrupt force. Allows software generation of interrupts for each possible source for functional or debug purposes.
0 No interrupt forced on corresponding interrupt source
1 Force an interrupt on the corresponding source
IPSBAR
Offset: 0x0C14 (INTFRCLn)
Access: Read/write
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
R
INTFRCL[31:16]
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
INTFRCL[15:1]
0
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 14-6. Interrupt Force Register Low (INTFRCLn)
Table 14-8. INTFRCLn Field Descriptions
Field Description
31–1
INTFRCL
Interrupt force. Allows software generation of interrupts for each possible source for functional or debug purposes.
0 No interrupt forced on corresponding interrupt source
1 Force an interrupt on the corresponding source
0 Reserved, should be cleared.
