Register Memory Map Quick Reference
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor A-17
IPSBAR + 0x1A_0009 GPT Control Register 1 GPTCTL1 8
IPSBAR + 0x1A_000B GPT Control Register 2 GPTCTL2 8
IPSBAR + 0x1A_000C GPT Interrupt Enable Register GPTIE 8
IPSBAR + 0x1A_000D GPT System Control Register 2 GPTSCR2 8
IPSBAR + 0x1A_000E GPT Flag Register 1 GPTFLG1 8
IPSBAR + 0x1A_000F GPT Flag Register 2 GPTAFLG2 8
IPSBAR + 0x1A_0010 GPT Channel 0 Register GPTC0 16
IPSBAR + 0x1A_0012 GPT Channel 1 Register GPTC1 16
IPSBAR + 0x1A_0014 GPT Channel 2 Register GPTC2 16
IPSBAR + 0x1A_0016 GPT Channel 3 Register GPTC3 16
IPSBAR + 0x1A_0018 Pulse Accumulator Control Register GPTPACTL 8
IPSBAR + 0x1A_0019 Pulse Accumulator Flag Register GPTPAFLG 8
IPSBAR + 0x1A_001A Pulse Accumulator Counter Register GPTPACNT 16
IPSBAR + 0x1A_001D GPT Port Data Register GPTPORT 8
IPSBAR + 0x1A_001E GPT Port Data Direction Register GPTDDR 8
Pulse-Width Modulator
IPSBAR + 0x1B_0000 PWM Enable Register PWME 8
IPSBAR + 0x1B_0001 PWM Polarity Register PWMPOL 8
IPSBAR + 0x1B_0002 PWM Clock Select Register PWMCLK 8
IPSBAR + 0x1B_0003 PWM Prescale Clock Select Register PWMPRCLK 8
IPSBAR + 0x1B_0004 PWM Center Align Enable Register PWMCAE 8
IPSBAR + 0x1B_0005 PWM Control Register PWMCTL 8
IPSBAR + 0x1B_0008 PWM Scale A Register PWMSCLA 8
IPSBAR + 0x1B_0009 PWM Scale B Register PWMSCLB 8
IPSBAR + 0x1B_000C PWM Channel Counter Register 0 PWMCNT0 8
IPSBAR + 0x1B_000D PWM Channel Counter Register 1 PWMCNT1 8
IPSBAR + 0x1B_000E PWM Channel Counter Register 2 PWMCNT2 8
IPSBAR + 0x1B_000F PWM Channel Counter Register 3 PWMCNT3 8
IPSBAR + 0x1B_0010 PWM Channel Counter Register 4 PWMCNT4 8
IPSBAR + 0x1B_0011 PWM Channel Counter Register 5 PWMCNT5 8
IPSBAR + 0x1B_0012 PWM Channel Counter Register 6 PWMCNT6 8
IPSBAR + 0x1B_0013 PWM Channel Counter Register 7 PWMCNT7 8
Table A-3. Register Memory Map (continued)
Address Name Mnemonic Size (bits)
