UART Modules
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor 24-13
24.3.9 UART Auxiliary Control Register (UACRn)
The UACRs control the input enable.
24.3.10 UART Interrupt Status/Mask Registers (UISRn/UIMRn)
The UISRs, shown in Figure 24-12 , provide status for all potential interrupt sources. UISRn contents are
masked by UIMRn. If corresponding UISRn and UIMRn bits are set, internal interrupt output is asserted.
If a UIMRn bit is cleared, state of the corresponding UISRn bit has no effect on the output.
The UISRn and UIMRn registers share the same space in memory. Reading this register provides the user
with interrupt status, while writing controls the mask bits.
Table 24-8. UIPCRn Field Descriptions
Field Description
7–5 Reserved
4
COS
Change of state (high-to-low or low-to-high transition).
0 No change-of-state since the CPU last read UIPCRn. Reading UIPCRn clears UISRn[COS].
1 A change-of-state longer than 25–50
μs occurred on the UCTSn input. UACRn can be programmed to generate
an interrupt to the CPU when a change of state is detected.
3–1 Reserved
0
CTS
Current state of clear-to-send. Starting two serial clock periods after reset, CTS reflects the state of UCTSn. If
UCTSn is detected asserted at that time, COS is set, which initiates an interrupt if UACRn[IEC] is enabled.
0 The current state of the UCTSn input is asserted.
1 The current state of the UCTSn input is deasserted.
IPSBAR
Offset:
0x00_0210 (UACR0)
0x00_0250 (UACR1)
0x00_0290 (UACR2) Access: User write-only
7 6 5 4 3 2 1 0
R
W 0 0 0 0 0 0 0 IEC
Reset: 0 0 0 0 0 0 0 0
Figure 24-11. UART Auxiliary Control Registers (UACRn)
Table 24-9. UACRn Field Descriptions
Field Description
7–1 Reserved, must be cleared.
0
IEC
Input enable control.
0 Setting the corresponding UIPCRn bit has no effect on UISRn[COS].
1 UISRn[COS] is set and an interrupt is generated when the UIPCRn[COS] is set by an external transition on the
UCTSn input (if UIMRn[COS] = 1).
