ColdFire Core
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor 3-31
3.3.5.7 Branch Instruction Execution Times
Table 3-18. General Branch Instruction Execution Times
Opcode
Effective Address
Rn (An) (An)+ -(An)
(d16,An)
(d16,PC)
(d8,An,Xi*SF)
(d8,PC,Xi*SF)
xxx.wl #xxx
BRA — — — — 2(0/1) — — —
BSR — — — — 3(0/1) — — —
JMP — 3(0/0) — — 3(0/0) 4(0/0) 3(0/0) —
JSR — 3(0/1) — — 3(0/1) 4(0/1) 3(0/1) —
RTE — — 10(2/0) — — — — —
RTS — — 5(1/0) — — — — —
Table 3-19. Bcc Instruction Execution Times
Opcode
Forward
Taken
Forward
Not Taken
Backward
Taken
Backward
Not Taken
Bcc 3(0/0) 1(0/0) 2(0/0) 3(0/0)
