Register Memory Map Quick Reference
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor A-15
Reset Control, Chip Configuration, and Power Management Registers
IPSBAR + 0x11_0000 Reset Control Register RCR 8
IPSBAR + 0x11_0001 Reset Status Register RSR 8
IPSBAR + 0x11_0004 Chip Configuration Register CCR 16
IPSBAR + 0x11_0007 Low-Power Control Register LPCR 8
IPSBAR + 0x11_0008 Reset Configuration Register RCON 16
IPSBAR + 0x11_000A Chip Identification Register CIR 16
Clock Module Registers
IPSBAR + 0x12_0000 Synthesizer Control Register SYNCR 16
IPSBAR + 0x12_0002 Synthesizer Status Register SYNSR 16
IPSBAR + 0x12_0004 Relaxation Oscillator Control Register ROCR 16
IPSBAR + 0x12_0007 Low Power Divider Register LPDR 16
IPSBAR + 0x12_0008 Clock Control High Register CCHR 8
IPSBAR + 0x12_0009 Clock Control Low Register CCLR 8
IPSBAR + 0x12_000A Oscillator Control High Register OCHR 8
IPSBAR + 0x12_000B Oscillator Control Low Register OCLR 8
IPSBAR + 0x12_0012 Real-Time Clock Control Register RTCCR 8
IPSBAR + 0x12_0013 Backup Watchdog Timer Control Register BWCR 8
Edge Port Registers
IPSBAR + 0x13_0000 EPORT Pin Assignment Register EPPAR 16
IPSBAR + 0x13_0002 EPORT Data Direction Register EPDDR 8
IPSBAR + 0x13_0003 EPORT Interrupt Enable Register EPIER 8
IPSBAR + 0x13_0004 EPORT Data Register EPDR 8
IPSBAR + 0x13_0005 EPORT Pin Data Register EPPDR 8
IPSBAR + 0x13_0006 EPORT Flag Register EPFR 8
Backup Watchdog Timer Registers
IPSBAR + 0x14_0000 Backup Watchdog Timer Control Register WCR 8
IPSBAR + 0x14_0002 Backup Watchdog Timer Modulus Register WMR 16
IPSBAR + 0x14_0004 Backup Watchdog Timer Count Register WCNTR 16
IPSBAR + 0x14_0006 Backup Watchdog Timer Service Register WSR 16
Table A-3. Register Memory Map (continued)
Address Name Mnemonic Size (bits)
