ColdFire Core
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor 3-27
3.3.5.3 Standard One Operand Instruction Execution Times
(d8,Ay,Xi*SF) 3(1/0) 3(1/1) 3(1/1) 3(1/1) — — —
xxx.w 2(1/0) 2(1/1) 2(1/1) 2(1/1) — — —
xxx.l 2(1/0) 2(1/1) 2(1/1) 2(1/1) — — —
(d16,PC) 2(1/0) 2(1/1) 2(1/1) 2(1/1) 2(1/1) — —
(d8,PC,Xi*SF) 3(1/0) 3(1/1) 3(1/1) 3(1/1) — — —
#xxx 1(0/0) 2(0/1) 2(0/1) 2(0/1) — — —
Table 3-14. One Operand Instruction Execution Times
Opcode
Effective Address
Rn (An) (An)+ -(An) (d16,An) (d8,An,Xn*SF) xxx.wl #xxx
BITREV Dx 1(0/0) — — — — — — —
BYTEREV Dx 1(0/0) — — — — — — —
CLR.B 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1) —
CLR.W 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1) —
CLR.L 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1) —
EXT.W Dx 1(0/0) — — — — — — —
EXT.L Dx 1(0/0) — — — — — — —
EXTB.L Dx 1(0/0) — — — — — — —
FF1 Dx 1(0/0) — — — — — — —
NEG.L Dx 1(0/0) — — — — — — —
NEGX.L Dx 1(0/0) — — — — — — —
NOT.L Dx 1(0/0) — — — — — — —
SCC Dx 1(0/0) — — — — — — —
SWAP Dx 1(0/0) — — — — — — —
TST.B 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)
TST.W 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)
TST.L 1(0/0) 2(1/0) 2(1/0) 2(1/0) 2(1/0) 3(1/0) 2(1/0) 1(0/0)
Table 3-13. MOVE Long Execution Times (continued)
Source
Destination
Rx (Ax) (Ax)+ -(Ax) (d16,Ax) (d8,Ax,Xi*SF) xxx.wl
