General Purpose I/O Module
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor 13-5
13.6.2 Port Data Direction Registers (DDRn)
The DDRn registers control the direction of the port n pin drivers when the pins are configured for digital
I/O.
The DDRn registers with a full 8-bit implementation are shown in Figure 13-7 . The remaining DDRn
registers use fewer than eight bits. Their bit definitions are shown in Figure 13-8 , Figure 13-9 ,
Figure 13-10 , and Figure 13-11 . The fields are described in Table 13-3 , which applies to all DDRn
registers.
The DDRn registers are read/write. At reset, all bits in the DDRn registers are cleared.
IPSBAR
Offset: 0x10_000C (PORTQS)
Access: User read/write
7 6 5 4 3 2 1 0
R 0
PORTn6 PORTn5 PORTn4 PORTn3 PORTn2 PORTn1 PORTn0
W
Reset: 0 1 1 1 1 1 1 1
Figure 13-4. Port QS Output Data Register (PORTQS)
IPSBAR
Offset: 0x10_0008 (PORTNQ)
Access: User read/write
7 6 5 4 3 2 1 0
R
PORTn7 PORTn6 PORTn5 PORTn4 PORTn3 PORTn2 PORTn1
0
W
Reset: 1 1 1 1 1 1 1 0
Figure 13-5. Port NQ Output Data Register (PORTNQ)
IPSBAR
Offset: 0x10_000B (PORTAS)
Access: User read/write
7 6 5 4 3 2 1 0
R 0 0 0 0 0 0
PORTn1 PORTn0
W
Reset: 0 0 0 0 0 0 1 1
Figure 13-6. Port AS Output Data Register (PORTAS)
Table 13-2. PORTn Field Descriptions
Field Description
Portnx Data to be driven when the port pin is configured as a digital output.
1 Output is a logic 1
0 Output is a logic 0
