Register Memory Map Quick Reference
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor A-11
IPSBAR + 0x0FFC Global Level 6 Interrupt Acknowledge Register GL7IACK 8
GPIO Registers
IPSBAR + 0x10_0000 Reserved — 8
IPSBAR + 0x10_0001 Reserved — 8
IPSBAR + 0x10_0002 Reserved — 8
IPSBAR + 0x10_0003 Reserved — 8
IPSBAR + 0x10_0004 Reserved — 8
IPSBAR + 0x10_0005 Reserved — 8
IPSBAR + 0x10_0006 Reserved — 8
IPSBAR + 0x10_0007 Reserved — 8
IPSBAR + 0x10_0008 Port NQ Out Data Register PORTNQ 8
IPSBAR + 0x10_0009 Reserved — 8
IPSBAR + 0x10_000A Port AN Output Data Register PORTAN 8
IPSBAR + 0x10_000B Port AS Output Data Register PORTAS 8
IPSBAR + 0x10_000C Port QS Output Data Register PORTQS 8
IPSBAR + 0x10_000D Reserved — 8
IPSBAR + 0x10_000E Port TA Output Data Register PORTTA 8
IPSBAR + 0x10_000F Port TC Output Data Register PORTTC 8
IPSBAR + 0x10_0010 Port TD Output Data Register PORTTD 8
IPSBAR + 0x10_0011 Port UA Output Data Register PORTUA 8
IPSBAR + 0x10_0012 Port UB Output Data Register PORTUB 8
IPSBAR + 0x10_0013 Port UC Output Data Register PORTUC 8
IPSBAR + 0x10_0014 Port DD Output Data Register PORTDD 8
IPSBAR + 0x10_0015 Reserved — 8
IPSBAR + 0x10_0016 Reserved — 8
IPSBAR + 0x10_0017 Reserved — 8
IPSBAR + 0x10_0018 Reserved — 8
IPSBAR + 0x10_0019 Reserved — 8
IPSBAR + 0x10_001A Reserved — 8
IPSBAR + 0x10_001B Reserved — 8
IPSBAR + 0x10_001C Reserved — 8
IPSBAR + 0x10_001D Reserved — 8
Table A-3. Register Memory Map (continued)
Address Name Mnemonic Size (bits)
