Register Memory Map Quick Reference
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
Freescale Semiconductor A-7
I 2 C1 Registers
IPSBAR + 0x0300 I 2 C Address Register 1 I2ADR1 8
IPSBAR + 0x0304 I 2 C Frequency Divider Register 1 I2FDR1 8
IPSBAR + 0x0308 I
2
C Control Register 1 I2CR1 8
IPSBAR + 0x030C I
2
C Status Register 1 I2SR1 8
IPSBAR + 0x0310 I
2
C Data I/O Register 1 I2DR1 8
Real-Time Clock Registers
IPSBAR + 0x03C0 RTC Hours and Minutes Counter Register HOURMIN 32
IPSBAR + 0x03C4 RTC Seconds Counter Register SECONDS 32
IPSBAR + 0x03C8 RTC Hours and Minutes Alarm Register ALRM_HM 32
IPSBAR + 0x03CC RTC Seconds Alarm Register ALRM_SEC 32
IPSBAR + 0x03D0 RTC Control Register RTCCTL 32
IPSBAR + 0x03D4 RTC Interrupt Status Register RTCISR 32
IPSBAR + 0x03D8 RTC Interrupt Enable Register RTCIENR 32
IPSBAR + 0x03DC RTC Stopwatch Minutes Register STPWCH 32
IPSBAR + 0x03E0 RTC Days Counter Register DAYS 32
IPSBAR + 0x03E4 RTC Day Alarm Register ALRM_DAY 32
IPSBAR + 0x03F4 RTC General Oscillator Count Upper Register RTCGOCU 16
IPSBAR + 0x03F8 RTC General Oscillator Count Lower Register RTCGOCL 16
DMA Timer Registers
IPSBAR + 0x0400 DMA Timer Mode Register 0 DTMR0 16
IPSBAR + 0x0402 DMA Timer Extended Mode Register 0 DTXMR0 8
IPSBAR + 0x0403 DMA Timer Event Register 0 DTER0 8
IPSBAR + 0x0404 DMA Timer Reference Register 0 DTRR0 32
IPSBAR + 0x0408 DMA Timer Capture Register 0 DTCR0 32
IPSBAR + 0x040C DMA Timer Counter Register 0 DTCN0 32
IPSBAR + 0x0440 DMA Timer Mode Register 1 DTMR1 16
IPSBAR + 0x0442 DMA Timer Extended Mode Register 1 DTXMR1 8
IPSBAR + 0x0443 DMA Timer Event Register 1 DTER1 8
IPSBAR + 0x0444 DMA Timer Reference Register 1 DTRR1 32
IPSBAR + 0x0448 DMA Timer Capture Register 1 DTCR1 32
IPSBAR + 0x044C DMA Timer Counter Register 1 DTCN1 32
Table A-3. Register Memory Map (continued)
Address Name Mnemonic Size (bits)
