Register Memory Map Quick Reference
MCF52211 ColdFire® Integrated Microcontroller Reference Manual, Rev. 2
A-6 Freescale Semiconductor
IPSBAR + 0x0288 (Read) Reserved 8
(Write) UART Command Register 2 UCR2 8
IPSBAR + 0x028C (Read) UART Receive Buffer 2 URB2 8
(Write) UART Transmit Buffer 2 UTB2 8
IPSBAR + 0x0290 (Read) UART Input Port Change Register 2 UIPCR2 8
(Write) UART Auxiliary Control Register 2 1 UACR2 8
IPSBAR + 0x0294 (Read) UART Interrupt Status Register 2 UISR2 8
(Write) UART Interrupt Mask Register 2 UIMR2 8
IPSBAR + 0x0298 (Read) Reserved 8
UART Baud Rate Generator Register 12 UBG12 8
IPSBAR + 0x029C (Read) Reserved 8
UART Baud Rate Generator Register 22 UBG22 8
IPSBAR + 0x02B4 (Read) UART Input Port Register 2 UIP2 8
(Write) Reserved 8
IPSBAR + 0x02B8 (Read) Reserved 8
(Write) UART Output Port Bit Set Command Register 2 UOP12 8
IPSBAR + 0x02BC (Read) Reserved 8
(Write) UART Output Port Bit Reset Command Register 2 UIP02 8
I 2 C0 Registers
IPSBAR + 0x0300 I 2 C Address Register 0 I2ADR0 8
IPSBAR + 0x0304 I 2 C Frequency Divider Register 0 I2FDR0 8
IPSBAR + 0x0308 I
2
C Control Register 0 I2CR0 8
IPSBAR + 0x030C I
2
C Status Register 0 I2SR0 8
IPSBAR + 0x0310 I
2
C Data I/O Register 0 I2DR0 8
QSPI Registers
IPSBAR + 0x0340 QSPI Mode Register QMR 16
IPSBAR + 0x0344 QSPI Delay Register QDLYR 16
IPSBAR + 0x0348 QSPI Wrap Register QWR 16
IPSBAR + 0x034C QSPI Interrupt Register QIR 16
IPSBAR + 0x0350 QSPI Address Register QAR 16
IPSBAR + 0x0354 QSPI Data Register QDR 16
Table A-3. Register Memory Map (continued)
Address Name Mnemonic Size (bits)
