BX600 S3 Operating Manual 87
Ethernet I/O Blades Cisco Catalyst Blade Switch 3040
The information necessary for configuring and operating the Cisco Catalyst
Blade Switch 3040 can be found in the manual „PRIMERGY BX Blade Server
Systems: Cisco Catalyst Blade Switch 3040“, see
“Related Publications” on
page 157 ).
4 Gigabit Ethernet ports
5 Gigabit Ethernet port indicators (bicolor LEDs)
Dark: No link established.
Glows green: Link established but no activity.
Blinks green: Traffic on an established link.
Glows amber: Port disabled, either error or STP1 disabled.
Glows green or
amber Link fault.
6 SFP module ports
7 SFP module port indicators (bicolor LEDs)
Dark: No link established.
Glows green: Link established but no activity.
Blinks green: Traffic on an established link.
Glows amber: Port disabled, either error or STP1 disabled.
Glows green or
amber Link fault.
