Page 104
104
Operating Manual
BX600
S3
2/4 Gbit FC Switch Blade SW4016
Fibre Channel I/O Blades
©
c
ogn
it
a
s
.
G
e
s
e
lls
c
h
ft
f
ü
r T
e
c
h
ni
k
-D
o
k
u
m
e
n
ta
ti
on m
b
H
20
09
P
fad
:
H
:\
A
p
ri
l\
P
R
IM
E
R
GY
_R
eb
rand
in
g
\v
o
n W
a
lt
er
\b
x
600
_s
3_
ba\
B
X
6
0
0
S
3
_
e
n
\b
la
d
e
-u
s.
k0
9
9.2
2/4 Gbit Fibre Channel Switch Blade
(Brocade SilkWorm 4016)
The 2/4 Gbit Fibre Channel Switch Blade (Brocade SilkWorm 4016) differs from
the 4/4 Gbit Fibre Channel Switch Blade in the maximum possible transfer rates.
It offers transfer rates of 2 Gbit/s via the internal ports to the server blades, and
4 Gbit/s via the external ports.
The 2/4 Gbit Fibre Channel Switch Blade has the same control and connection
panel as the 4/4 Gbit Fibre Channel Switch Blade, see
7
LAN activity indicator of the FC switch blade (amber LED)
Dark:
No connection
Lights:
LAN connection is available
Blinks:
Data transport
8
Status display of ext. FC ports (2-color LED)
Dark:
No signal reception
Flickers green:
FC port on-line, data transport
Blinks green:
–
slow: FC port on-line, but segmented.
–
fast: internal loop
Lights amber:
Signal reception, but not on-line
Blinks amber:
slow (~ 2 sec. intervals): FC port disabled.
fast (~ 0.5 sec. interval): FC port faulty
9
Speed display of ext. FC port (2-color LED)
Dark:
FC transfer rate 1Gbit/s
Lights green:
FC transfer rate 2Gbit/s
Lights amber:
FC transfer rate 4Gbit/s
