BX600 S3 Operating Manual 41
Installing the Hardware Connecting External Devices
Ê Insert the server blades into their slots (see section “Adding a Server Blade
to the Basic Unit” on page 74 ). Return the power supply units and fan units
to the basic unit (see section “Replacing a Power Supply Unit” on page 133
and section “Replacing the Fan Unit” on page 141 ).
You remove the basic unit by following the above steps in reverse order:
V
CAUTION!
Please note the relevant safety instructions in section “Notes on Installing
in the Rack” on page 27 .
Ê Note the slot assignment of the server blades so that you can insert them
correctly again after you have removed the basic unit from the rack.
Ê Remove server blades, fan units and power supplies from the basic unit to
reduce weight.
Ê Remove the four knurled screws.
Ê Pull out the basic unit and carefully remove it from the rack.
4.4 Connecting External Devices
The external connectors of the PRIMERGY BX600 S3 basic unit are located on
the rear of the basic unit. The external connectors of the server blades are
located on the front of the basic unit. For information on these connectors see
the operating manuals of the different server blade types (see
“Related Publica-
tions” on page 157 ).
