BX600 S3
Operating Manual
81
Ethernet I/O Blades
Ethernet Switch Blade (SB9) 6x1Gbit
The information necessary for configuring and operating the Gbit Ethernet LAN
switch blade (SB9) 6x1Gbit can be found in the manual „PRIMERGY BX Blade
Server Systems: LAN Router and Switch Blade - User Interface Description“,
see
“Related Publications” on page 157
).
8.2
GbE Intelligent Blade Panel (IBP) 10/6
The GbE Intelligent Blade Panel (IBP) 10/6 is a LAN connection module in-
between a pass-thru and a switch. It combines the switch advantage of cable
and port consolidation with the pass-thru advantage of working fully (VLAN)
transparent and the lack of any protocol compatibility issues. The IBP 10/6
offers the following connections:
–
10 internal 1Gbit downlink ports to the server blades
–
6 external 1Gbit uplink ports via RJ45 connectors
It provides the same control and connection panel as the
7
Power and system indicators (green LEDs)
P:
Power indicator (green LED)
Glows green:
Power enabled
Dark:
Power disabled
S:
System indicator (green LED)
Glows green:
Selected for identification by the management blade
Blinks green:
Error occurred
