BX600 S3 Operating Manual 77
Server Blades Adding a Server Blade to the System
I
How to install a server blade is described in the following using the
example of a 2-way server blade. 4-way server blades are installed in the
same way.
Figure 32: Inserting the server blade
Ê Push the server blade into the slot as far as possible while keeping the eject
handles in the unlocked position.
I
Please make sure you install the server blade in the right direction.
The upper narrow side of the server blade is marked TOP-SIDE (1).
1
