Page 122
122
Operating Manual
BX600
S3
Adv. KVM Blade
KVM Blade
©
c
ogn
it
a
s
.
G
e
s
e
lls
c
h
ft
f
ü
r T
e
c
h
ni
k
-D
o
k
u
m
e
n
ta
ti
on m
b
H
20
09
P
fad
:
H
:\
A
p
ri
l\
P
R
IM
E
R
GY
_R
eb
rand
in
g
\v
o
n W
a
lt
er
\b
x
600
_s
3_
ba\
B
X
6
0
0
S
3
_
e
n
\b
la
d
e
-u
s.
k1
1
1
Rear ID button
If you press the ID button, the ID LED on the rear lights up. The front and
the rear ID LEDs are synchronized.
2
Rear ID/error LED (green LED)
Glows green:
The system has been selected for identification by
pressing the front or rear ID button (LED glows).
Press one of the ID buttons to deactivate the ID LED.
Blinks green:
Checksum error: System error.
3
KVM connector
Supports the connection of a VGA monitor, PS2 keyboard and PS2
mouse via a special cable (see
4
LAN connection (with two integrated LAN status LEDs (see the
following items 5 and 6))
LAN port, RJ45, 10/100 Mbit/s.
5
LAN activity indicator (green LED)
Dark:
LAN connection not active.
Blinks green:
Active LAN connection.
6
LAN connection indicator (orange LED)
Dark:
No connection.
Glows:
LAN connection available.
