BX600 S3 Operating Manual 119
11 KVM Blade
For administering the server blades, the PRIMERGY BX600 S3 basic unit offers
a KVM blade, which allows the individual server blades to be connected to a
console.
Figure 65: Position of the KVM blade
The following models are available:
– KVM blade (standard version)
– Adv. KVM blade
– Digital KVM blade
11.1 KVM Blade (Standard Version)
The standard KVM blade allows a monitor, PS2 keyboard and PS2 mouse to be
connected for local administration of the server blades. This requires a special
cable (see
figure 10 on page 43 ). The server blade is assigned to the KVM
blade by pressing the KVM button on the control panel of the server blade to be
administered.
KVM blade
