Ethernet I/O Blades Ethernet Switch Blade (SB9F) 12x1 Gbit
8.5 GbE Intelligent Blade Panel (IBP) 30/12
The GbE Intelligent Blade Panel (IBP) 30/12 is a LAN connection module in-
between a pass-thru and a switch. It combines the switch advantage of cable
and port consolidation with the pass-thru advantage of working fully (VLAN)
transparent and the lack of any protocol compatibility issues. The IBP 30/12
offers the following connections:
– 30 internal 1Gbit downlink ports to the server blades
– 12 external 1Gbit uplink ports via RJ45 connectors
It provides the same control and connection panel as the Gbit Ethernet LAN
Switch Blade (SB9F) 12x1 Gbit .
13 Power and system indicator
P: Power indicator (green LED)
Glows green: Power enabled
Dark: Power disabled
S: System indicator (green LED)
Glows green: ID indicator was enabled via the management blade
Blinks green: Error occurred
