Preface Features
Gbit Ethernet LAN Switch Blade (SB9F) 12x1 Gbit
– 30 internal 1Gbit ports to the server blades
– 12 external 1Gbit ports (RJ45)
I
This switch blade can only be installed in slots NET1 and
NET2. The number of available ports depends on the types of
server blades installed, see
page 80 .
10 Gbit switch blade 10/2
– 10 internal 10 Gbit/s ports to the server blades
– 2 external 10 Gbit/s ports with optional X2 transceiver modules for
Fiber-Optical or CX4 copper cable
I
This switch blade can only be installed in slots NET3 and
NET4 and supports only server blades with a 10-GbE
daughter card, see
page 84 .
Ethernet LAN Pass-Thru-Blade
This I/O blade provides ten RJ45 ports for direct (“pass-thru”) connections
to the server blades.
– 10 internal 1Gbit ports to the server blades
– 10 external 1Gbit ports (RJ45)
All switch blades are hot-swappable. By installing two switch blades,
redundant LAN connections can be provided for the server blades.
● Fibre Channel I/O Blades
The following I/O blades are available for connecting the server blades to
SAN environments:
2/4 Gbit Fibre Channel Switch Blade Brocade SilkWorm 4016
– 10 internal 2Gbit/s ports to the server blades
– 6 external 4Gbit/s ports via a GBIC/SFP module
I
In addition to the 16-port variant, a model with 12 dynamically
assignable ports is available (e.g. 4 external and 8 internal
ports). You can upgrade this model to a 16-port variant later.
