Page 66
66
Operating Manual
BX600
S3
Updating BX600 System Components
Preparation for Use and Operation
©
c
ogn
it
a
s
.
G
e
s
e
lls
c
h
ft
f
ü
r T
e
c
h
ni
k
-D
o
k
u
m
e
n
ta
ti
on m
b
H
20
09
P
fad
:
H
:\
A
p
ri
l\
P
R
IM
E
R
GY
_R
eb
rand
in
g
\v
o
n W
a
lt
er
\b
x
600
_s
3_
ba\
B
X
6
0
0
S
3
_
e
n
\b
la
d
e
-u
s.
k0
5
Ê
Extract the firmware file to the root directory of the TFTP file system. For
information on the image file names, see the
readme
file of the update
package.
Ê
Start an Internet browser on the client server. Enter the IP address specified
above in the address field. Enter the user name and password admin. The
home page is displayed.
Ê
In the navigation bar choose
Flash/File
.
I
Only two operation code image files can be stored on the switch blade. If
there are already two image files stored, you must remove at least one of
them before updating the firmware. It is recommended that you remove
the older file (i.e. the file with the lower number).
Ê
Expand the
File Name
list (red arrow) in the
Remove Operation Code Image File
section to check if there are already two image files stored on the switch
blade. If so, select the older one in the
File Name
list and click
Remove File
.
Figure 24: Removing an operation code image file
Ê
Enter
TFTP Server IP Address
,
Source File Name
and
Destination File Name
.
