FUJITSU PRIMERGY BX600 S3 - Manual (Page 124)

124 Operating Manual BX600 S3
Digital KVM Blade KVM Blade
©
c
ogn
it a
s .
G
e
s e lls
c h ft
f ü r T
e c h
ni
k -D
o k u m
e
n ta
ti on m
b
H
20
09
P
fad
:
H
:\ A
p
ri l\ P
R
IM
E
R
GY
_R
eb
rand
in
g
\v
o
n W
a lt er
\b
x 600
_s
3_
ba\
B
X
6
0 0 S
3
_ e n
\b
la
d
e -u
s.
k1
1
Control panel of the digital KVM blade
Figure 68: Digital KVM blade
1 LAN connection
LAN port, RJ45, 10/100 Mbit/s.
LED A: LAN transfer rate indicator
LED B: LAN link indicator
2 Power indicator
Glows: Power enabled
Blinks: Power disabled
2 KVM connection
Offers support for VGA and PS2 keyboard and mouse via a special
cable (see
figure 10 on page 43 ) or for the connection to an external
console switch.
4 ID indicator
Glows: The system has been selected for identification by
pressing the front or rear ID button.
Blinks: System failure
3 1 2 4
