RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.5) 10-6
Reviewing the Motor Locations and Cables
Motor Cable Location
Flipper Table Motor (840124) D860130 J31
Flip / Feed Motor
(E000062 & D840861)
D860129 J34
Card Drive Stepper (D860138 D860119 J33
Print Stepper (840123) D860120 J32
Hopper Motor (D840980) D860117 J28 (1-2)
Lift Stack Motor (A000124 & 760286) D860117 J28 (3-4)
In Feed Motor (D840980) D860123 J30 (5-6)
Transfer Lift Motor (D860055) D860115 J30 (3-4)
Print Lift Motor
D860097
D860116 J30 (1-2)
Ribbon Take Up Motor
D840980
D860154 J29 (5-6)
Ribbon Supply Motor
D840980
D860153 J29 (1-2)
Film Take Up Motor
D860097
D860152 J29 (7-8)
Film Supply Motor
D860055
D860115 J29 (3-4)
