Hale 5.0 FoamLogix - Manual (Page 79)

DESCRIPTION, INSTALLATION AND
OPERATION MANUAL
HALE PRODUCTS, INC. l A Unit of IDEX Corporation l 700 Spring Mill Avenue l Conshohocken, PA 19428 l TEL: 610-825-6300 l FAX: 610-825-6440
Hale Products cannot assume responsibility for product failure resulting from improper
maintenance or operation. Hale Products is responsible only to the limits stated in the product
warranty. Product specifications contained in this material are subject to change without notice.
FoamLogix
TM
MODEL 3.3 AND 5.0 ROTARY GEAR
PUMP ELECTRONIC FOAM
PROPORTIONING SYSTEM
SECTION III
SET-UP AND CALIBRATION
NOTICE: This manual section is used by the installer and end user for setting up and calibrating
the Hale foam proportioning system. This manual section also provides procedures for the end
user to change default values and verify calibration if different foam concentrates are used. This
manual section can be used as a stand alone section or in conjunction with other sections of the
complete manual.
