ROTARY GEAR PUMP
ELECTRONIC FOAM PROPORTIONING SYSTEM
FLOWSENSOR
CORDSET
DISTRIBUTION
BOX
BYPASS
VALVE
BYPASS
HOSE
FOAM
INJECTION
HOSE
WATERWAY
CHECK
VALVE
WATERWAY
CHECK
VALVE
FIRE
PUMP
FOAM PUMP AND
MOTOR
ASSEMBLY
CONTROL
CORDSET
FOAM SOLUTION
DISCHARGE(S)
FS-15 OR FS-25 PANEL
MOUNTED FOAM
STRAINER
FOAM
TANK
FOAM TANK
DRAIN
VALVE
FOAM TANK
SHUTOFF
VALVE
MST
SELECTOR
VALVE
CONTROL
UNIT
FLUSHING
WATER SUPPLY
CHECK VALVE
INJECTOR
FITTING
Figure 1-3. Hale Foam System Layout with Single Foam Concentrate Tank, MST and FS
Series Strainer
HALE
FLOWSENSOR
PADDLE WHEEL
MOUNTED IN
SADDLECLAMP
