16 Section
I
: Description
ROTARY GEAR PUMP
ELECTRONIC FOAM PROPORTIONING SYSTEM
Figure 1-1. Hale Foam System Layout with Single Foam Concentrate Tank
CONTROL
UNIT
DISTRIBUTION
BOX
FLOWSENSOR
CORDSET
BYPASS
VALVE
FOAM
INJECTION
HOSE
BYPASS
HOSE
WATERWAY
CHECK
VALVE
IN-LINE FOAM STRAINER/
VALVE ASSEMBLY
CONTROL
CORDSET
WATERWAY
CHECK
VALVE
HALE
FLOWSENSOR
PADDLE WHEEL
MOUNTED IN
SADDLECLAMP
CHECK VALVE
INJECTOR
FITTING
FOAM SOLUTION
DISCHARGE(S)
FIRE
PUMP
FOAM
TANK
FOAM TANK
DRAIN
VALVE
SIDE MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
TOP MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
BOTTOM MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
FLUSHING
WATER SUPPLY
FOAM PUMP AND
MOTOR
ASSEMBLY
