Hale 5.0 FoamLogix User Manual
Page 120
IV
-26
ROTARY GEAR PUMP
ELECTRONIC FOAM PROPORTIONING SYSTEM
Section
IV
: Operation
HALE FOAMLOGIX AIR DUAL TANK VALVE (ADT)
538-1640-00-0
ADT VALVE ASSEMBLY (INCLUDES ITEMS MARKED
*
BELOW)
*
1
010-0660-00-0
INLET LINE STRAINER
1
EA
*
2
012-1430-00-0
"PULL TO BYPASS" KNOB
1
EA
3
018-1222-12-0
SCREW ¼-20 X 2-¼ IN LG
1
EA
*
4
018-1410-24-0
SCREW 5/16-18 X 1 IN LG
4
EA
5
038-1800-00-0
TOGGLE VALVE
1
EA
6
040-1180-00-0
40-3N118 SEAL RING
1
EA
7
040-1230-00-0
O-RING 123 BUNA
1
EA
8
082-0142-02-0
FITTING 1/8 NPT X ¼ TUBE PUSH CONN
2
EA
9
082-0143-02-0
ELBOW 1/8 NPT X ¼ TUBE PUSH CONN
2
EA
*
10
082-0408-02-0
½ INCH NPT CLOSE NIPPLE (BRASS)
1
EA
*
11
082-0414-02-0
½ INCH NPT SERVICE ELBOW (BRASS)
1
EA
*
12
082-0521-05-0
¾ NPT X ¾ INCH HOSE NYLON ELBOW (NOT SHOWN)
1
EA
*
13
082-0545-05-0
¾ NPT X 1 INCH HOSE NYLON ELBOW (NOT SHOWN)
1
EA
14
159-0760-00-0
SPACER
1
EA
15
200-0540-00-0
LIGHT ASSEMBLY (GREEN)
1
EA
16
200-0540-10-0
LIGHT ASSEMBLY (RED)
1
EA
17
200-1280-00-0
A-B INTERLOCK ASSEMBLY
1
EA
*
18
200-2450-00-0
SWITCH
2
EA
19
101-1630-00-0
ADT NAMEPLATE
1
EA
20
101-1630-07-0
FOAM SYSTEM DIAGRAM NAMEPLATE
(DUAL TANK)
1
EA
21
513-0300-00-0
ADT WIRING HARNESS
1
EA
22
538-1610-00-0
ADT SELECTOR PANEL ASSEMBLY
1
EA
23
538-1640-01-0
ADT VALVE ASSEMBLY
1
EA
24
507-0380-00-0
AIR HARNESS ASSEMBLY (OPTIONAL)
1
EA
REF
PART NUMBER DESCRIPTION
QTY
UNIT
