IV
-18
ROTARY GEAR PUMP
ELECTRONIC FOAM PROPORTIONING SYSTEM
Section
IV
: Operation
Chart 4-1. Hale FoamLogix System Troubleshooting
START
ENERGIZE THE APPARATUS FOR NORMAL OPERATION
AND SUPPLY POWER TO PUMP OPERATOR PANEL
PROCEED TO
POWER SUPPLY
TROUBLESHOOTING
CHART 4-2
ENERGIZE FOAMLOGIX SYSTEM AND
ESTABLISH FOAM FLOW. REFER TO
SECTION III FOR USER CALIBRATION
PROCEDURES TO CHECK FOAM FLOW
IS FOAMLOGIX CONTROL
UNIT ILLUMINATED?
FOR ADDITIONAL ASSISTANCE
CONTACT NEAREST HALE
SERVICE CENTER
YES
NO
REFER TO
APPARATUS
OPERATING
PROCEDURES
ENGAGE APPARATUS WATER
PUMP AND ESTABLISH WATER
FLOW. IS WATER FLOWING?
YES
NO
PROCEED TO HPF
FLOWSENSOR
TROUBLESHOOTING
CHART 4-3
DOES WATER FLOW RATE
SHOW ON CONTROL UNIT?
YES
NO
PROCEED TO
FOAM PUMP
TROUBLESHOOTING
CHART 4-4
IS FOAM PUMP FLOWING
FOAM CONCENTRATE?
YES
NO
PROCEED TO
FOAM PUMP USER
CALIBRATION IN
SECTION III
IS FOAM PUMP FLOWING
PROPER AMOUNT OF FOAM
CONCENTRATE?
YES
NO
