20 Section
I
: Description
ROTARY GEAR PUMP
ELECTRONIC FOAM PROPORTIONING SYSTEM
FLOWSENSOR
CORDSET
DISTRIBUTION
BOX
BYPASS
VALVE
BYPASS
HOSE
FOAM
INJECTION
HOSE
WATERWAY
CHECK
VALVE
WATERWAY
CHECK
VALVE
FIRE
PUMP
FOAM PUMP AND
MOTOR
ASSEMBLY CONTROL
CORDSET
FOAM SOLUTION
DISCHARGE(S)
BOTTOM MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
FS-15 OR FS-25 PANEL
MOUNTED FOAM
STRAINER
FOAM
TANK B
FOAM
TANK A
FOAM TANK
SHUTOFF
VALVE FOAM TANK
DRAIN VALVE
FOAM TANK
DRAIN VALVE
FOAM TANK
SHUTOFF
VALVE
MDT II
SELECTOR
VALVE
CONTROL
UNIT
FLUSHING
WATER SUPPLY
CHECK VALVE
INJECTOR
FITTING
SIDE MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
TOP MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
BOTTOM MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
SIDE MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
TOP MOUNT FOAM
TANK LOW LEVEL
SENSOR OPTION
Figure 1-5. Hale Foam System Layout with Dual Foam Concentrate Tanks, MDT
ΙΙ
and FS
Series Strainer Assembly
HALE
FLOWSENSOR
PADDLE WHEEL
MOUNTED IN
SADDLECLAMP
